Intel H55 Chipset,Intel Socket 1156 for 1st Gen Core i7/ i5/i3/Pentium/Celeron Processors,2 x DDR3,PCIE-X16,SATA 2.0,USB 2.0
supports intel core inside
READY FOR 1ST GENERATION INTEL CORE LGA1156 PROCESSORS
Processor |
Support Intel® Socket 1156 for 1st Generation Core™i7/ Core™ i5/Core™ i3/Pentium®/Celeron® Processors
|
Chipset | Intel® H55 |
Memory support |
2 * DDR3 1066/1333MHz DIMM
|
Graphic |
Integrated Graphics Processor- Intel® HD Graphics support Multi-VGA output support : HD / VGA ports |
Slots |
1 x PCIe x16 slot
1 x PCIe x1 slot |
Storage
|
4 x SATA 3Gb/s Ports |
LAN | Realtek Chip, 1 x 100M(Optional 1000M) |
Audio | Realtek Chip, ALC 662 6-channel audio |
USB |
10 * USB 2.0 port (6 at back panel, black, 4 at mid-board)
|
Back Panel I/O |
1 x VGA Port 1 x HDMI Port 1 x LAN (RJ45) Port 6 x USB 2.0 Ports 3 x flexible audio jacks
|
Internal I/O |
1 x USB 19pin connector, supports 2*USB 2.0 ports 1 x USB 2.0 connector, supports 2*USB 2.0 ports 4 x SATA 3Gb/s Ports 2 x 4 -pin CPU_FAN/SYS_FAN connectors 1 x 24-pin ATX power connector 1 x 4-pin 12V ATX Power connectors 1 x F_Audio connector 1 x Internal Speaker connector 1 x F_Panel connector
|
Dimension | 211 x 168mm |
