Intel HM76 Chipset; Supports Intel Socket 988 2nd/3rd Generation Core i3/i5/i7/Pentium/Celeron processors；Msata; MiniPCIe，DC-in
Highly integrated and highly reliable
Supports Socket 988 2nd/3rd Gen Intel® Core™ i3/i5/i7/Pentium /Celeron Processors
Intel® HM76 Chipset
Supports DDR3 memory that features data transfer rates of 1600/1066 MHz providing great
performance for 3D graphics and other memory-demanding applications
| Processor |
Support Intel® Socket 988 for 2nd/3rd Generation Core™i7/ Core™ i5/Core™ i3/Pentium®/Celeron® Processors |
| Chipset | Intel ® HM76 |
| Memory support |
1 x SO-DDR3L DIMM, MAX. 8G
|
| Graphic |
Integrated Graphics Processor- Intel® HD Graphics support Multi-VGA output support : HD/ VGA ports
LVDS ：Support 18Bit/24Bit LCD
|
| Slots |
1 x Mini PCIe Slot, Support MSATA ( SSD) |
|
Storage
|
2 x SATA 3Gb/s |
| LAN |
1 x RJ45 Realtek8111E Gigabit LAN (100M optional) |
| Audio | Realtek Chip, ALC 662 6-channel audio |
| COM | 1 x COM |
| USB |
2 x USB 3.0 ( at back panel )
7 x USB 2.0/1.1 (2 at back panel, black, 5 at mid-board) |
| Back Panel I/O |
1 x DC-in 1 x VGA 1 x HDMI 1 x LAN (RJ45) 2 x USB 3.0
2 x USB 2.0 1 x Headset 1 x Mic |
|
Internal I/O |
3 x USB 2.0 connectors， supports 5*USB 2.0ports 1 x COM connector 1 x LVDS_CON connector 1 x BLK_MON connector 1 x LCD_PWR connector 1 x INVERTER connector 1 x HDMI_CON connector 1 x DEBUG connector 2 x HDD_PWR connectors 1 x AUTO_PWR connector 1 x PWR_IN connector 1 x SPEAKER connector 1 x F_Panel connector 1 x F_audio connector 1 x Mini PCIE Slot 2 x SATA Slots |
| Watchdog | Provide software watchdog function, adjustable from 1-255/s |
|
Application Environment |
Working temperature: 0 ° C - 60 ° C Storage temperature -20 ° C - 80 ° C Relative temperature: 10% - 90% (no self-coagulation)
|
| Power |
DC12V/5A AC 100-240V ( Adapter required ) |
| Dimension | Mini ITX， 170 x 170mm |
| Name | Type | Size | Description |
|---|
