23.8 inch HD Full Screen，1920*1080，Support Intel for 8th/7th/6th/5th/4th/3th/2th Gen Core i7/ i5/i3, Pentium/Celeron Processors / AMD Ryzen Athlon CPU，WIFI，Bluetooth，m.2 SSD
| Screen | 23.8 inch HD Full Screen ( 1920 * 1080p),View angle H=178DEG,V=178DEG(CR>=10) |
| Processor |
Support Intel® for 8th/7th/6th/5th/4th/3th/2th Generation Core™ i7/Core™ i5/Core™i3, Pentium®/Celeron® Up to 65W Desktop Processors Support AMD Ryzen & 7-Gen A-Series / Athlon™ Processor (Optional) |
|
Motherboard Platform |
Intel Intel B360/H310/H110/H81/H61/HM55/HM65Thin Mini ITX AMD A320 Thin Mini ITX (OPtional) |
| Memory |
DDR4 / DDR3 Memory(Optional 8GB / 16GB 32GB ) |
| Extra Desktop |
1x M.2 2280/2260/2242 Slot Datachable 2.5" 500GB HDD (Optional SSD) |
| GPU |
Intel® HD Graphics |
| Ethernet |
WiFi 802.11ac Bluetooth 4.0 RJ45 10/100/1000Mbps |
|
Speaker
|
4Ω ，3W*2 |
| Rear IO |
1 * DC Power Jack, 1 * HD/ VGA 4 * USB 3.0 / 4 * USB 2.0 Ports,
1 * RJ45 Jack，1 * Headset Jack， 1 * Mic Jack |
|
Side IO |
2 * USB 3.0 / 2 * USB 2.0 Ports |
| Power Adapter |
DC 5.5mm 19V~4.74A / 19V~9.74A (1x 90W/120W/150W Power adaptor outside ) |
| Button |
1 * Power switch button, 1 * Reset switch button |
| KB/MS | 2.4G wireless keyboard and mouse set, or wired keyboard and mouse set (optional) |
| OS | Windows 10 |
|
Dimensions |
542.3mm (L)*320.7mm (H)*10mm-59.8mm (D) |
