H81DA1 V81

Intel? H81/B85 Chipset，Socket 1150 for 4th Gen Core i7/ i5/i3 Processors，M.2， DDR3，PCIE-X16，PCIE-X1

Features
Specifications
Download

supports intel core inside

READY FOR 4TH GENERATION INTEL CORE LGA1150 PROCESSORS

This motherboard supports 4th Generation Intel® Core™ processors in the LGA1150 package, with integrated graphics, memory and PCI Express controllers to support onboard graphics output with dedicated chipsets, dual-channel (2-DIMM) DDR3 memory and PCI Express 3.0/2.0 lanes for great performance.

Intel® H81 is a single-chipset design

supports 4th Generation Intel® Core™ LGA1150 processors. It provides improved performance by utilizing serial point-to-point links, allowing increased bandwidth and stability.

M.2 Slot

Supports M.2 Slot (Key M), supports 2242/2260/2280 type storage devices.

Dual-Channel DDR3 1066/1333MHz support

This motherboard supports DDR3 memory that features data transfer rates of 1066/1333MHz providing great performance for 3D graphics and other memory-demanding applications

PCI Express Architecture

PCI Express is the latest I/O interconnect technology that will replace the existing PCI. With a bus bandwidth 4 times higher than that of AGP 8X interface, PCI Express x16 bus performs much better than AGP 8X in applications such as 3D gaming.

SATA 6Gb/s

This motherboard supports hard drives based on the Serial ATA (SATA) 6Gb/s storage specifications, delivering enhanced scalability and doubling the bus bandwidth for high-speed data saving and retrieval.

USB 3.0

USB3.0 provides up to 5Gbps data transfer rate, supports hot swap, Compatible with USB 2.0 standard,Easy connection to various USB interface devices.

100M/1000M LAN(OPtional)

Providing high-quality 100M/1000M Ethernet performance to value-oriented consumers, its high-speed, stable features are best suited for today's broadband era

Processor	Support Intel® Socket 1150 for 4th Generation Core™i7/ Core™ i5/Core™ i3/Pentium®/Celeron® Processors
Chipset	Intel® H81 B85 Chipset
Memory support	2 * DDR3 1066/1333MHz DIMM
Graphic	Integrated Graphics Processor- Intel® HD Graphics support Multi-VGA output support : HDMI / VGA ports
Slots	1 x PCIe x16 3.0/2.0 slot 1 x PCIe x1 2.0 slot
Storage	1 x M.2 Socket, Supports 2242 SSD 4 x SATA 6Gb/s Ports
LAN	Realtek Chip, 1 x 100M（Optional 1000M）
Audio	Realtek Chip, ALC 6-channel audio
USB	4 * USB 3.0 port (2 at back panel, blue, 2 at mid-board) 6 * USB 2.0 port (4 at back panel, black, 2 at mid-board)
Back Panel I/O	1 x VGA Port 1 x HD Port 1 x LAN (RJ45) Port 2 x USB 3.0 Ports(Blue) 4 x USB 2.0 Ports 3 x flexible audio jacks
Internal I/O	1 x USB 3.0 connector（19pin)， supports 2USB 3.0 ports 1 x USB 2.0 connector， supports 2USB 2.0 ports 4 x SATA 6Gb/s Ports 1 x 4 -pin CPU_FAN/SYS_FAN connectors 1 x 24-pin ATX power connector 1 x 4-pin 12V ATX Power connectors 1 x DEBUG connector 1 x F_Audio connector 1 x Internal Speaker connector 1 x F_Panel connector
Dimension	190 x 170mm
