A75FSAL
A75FSAL
A75FSAL
A75FSAL

Support AMD Socket FS1 A8/A6/A4 series processors,2*DDR3 ,6*SATA

A75FSAL
A75FSAL
A75FSAL
Supports AMD® A8/A6/A4 Series Processors

This motherboard supports AMD® A8/A6/A4 series processors in FS1 package

Equipped with AMD RadeonTM HD series display chip

AMD® A75 Chipset
AMD® A75 is designed to support up to 5GT/s interface speed and PCI Express™ 2.0 x 16(at x4 speed)graphics
Dual-Channel DDR3 1866/1600/1333 support
This motherboard supports DDR3 memory that features data transfer rates of 1866/1600/1066 MHz providing great performance for 3D graphics and other memory-demanding applications
PCI Express Architecture
PCI Express is the latest I/O interconnect technology that will replace the existing PCI. With a bus bandwidth 4 times higher than that of AGP 8X interface, PCI Express x16 bus performs much better than AGP 8X in applications such as 3D gaming.
SATA 3Gb/s
This motherboard supports hard drives based on the Serial ATA (SATA) 3Gb/s storage specifications, delivering enhanced scalability and doubling the bus bandwidth for high-speed data saving and retrieval.
USB 2.0
USB2.0 provides up to 480Mbps data transfer rate, supports hot swap, Compatible with USB 2.0 standard,Easy connection to various USB interface devices.
100M/1000M LAN(OPtional)
The on-board LAN controller is a highly integrated 100 Mbit LAN / GbLAN controller. It is enhanced with an ACPI management function to provide efficient power management for advanced operating systems
Processors

Supports AMD  FS1 A8/A6/A4 series Processor

Supports AMD Socket FS1 series Processor

Chipset AMD® A75
Memory Support

2 * DDR3 1066/1333MHz DIMM

Slots

1 x PCIe x16 Slot

1 x PCIe X1  Slot

Storage

6 x SATA 2.0

LAN Realtek Chip, 1 x 100M(Optional 1000M)
Audio Realtek Chip, ALC 662 6-channel audio
USB

8 x USB 2.0  (4 at back panel, black, 4 at mid-board)

Back Panel I/O

1 x PS2 Keyboard / Mouse

4 x USB 2.0


1 x HDMI

1 x VGA

1 x LAN (RJ45)

3 x flexible audio jacks

Internal I/O

2 x USB 2.0 connectors, supports 4*USB 2.0 ports

6 x SATA 3Gb/s

1 x 4 -pin CPU_FAN connectors

1 x 24-pin ATX power connector

1 x 4-pin 12V ATX Power connectors

1 x F_Audio connector

1 x Internal Speaker connector

1 x F_Panel  connector

Dimension 211 x 168mm
