23.8 inch HD Full Screen,1920*1080,Support Intel for 8th/7th/6th/5th/4th/3th/2th Gen Core i7/ i5/i3, Pentium/Celeron Up to 65W Desktop Processors / AMD Ryzen Athlon CPU,WIFI,Bluetooth,m.2 SSD

AIO-GW24
AIO-GW24
AIO-GW24
AIO-GW24
AIO-GW24
AIO-GW24
Screen 23.8 inch HD Full Screen ( 1920 * 1080p),View angle H=178DEG,V=178DEG(CR>=10)
Processor

Support Intel® for 8th/7th/6th/5th/4th/3th/2th Generation Core™ i7/Core™ i5/Core™i3, Pentium®/Celeron® Up to 65W Desktop Processors

Support AMD Ryzen & 7-Gen A-Series / Athlon™ Processor  (Optional)

Motherboard
Platform

Intel Intel B360/H310/H110/H81/H61/HM55/HM65Thin Mini ITX

AMD A320 Thin Mini ITX  (OPtional)

Memory

DDR4 / DDR3 Memory(Optional 8GB / 16GB 32GB )

Extra Desktop

1x M.2 2280/2260/2242 Slot

Datachable 2.5"  500GB HDD (Optional SSD)

GPU

Intel® HD Graphics

Ethernet

WiFi 802.11ac

Bluetooth 4.0

RJ45 10/100/1000Mbps

Speaker

4Ω ,3W*2

Rear IO

1 * DC Power Jack, 1 * HDMI / VGA

4 * USB 3.0 / 4 * USB 2.0 Ports

1 * RJ45 Jack,1 * Headset Jack, 1 * Mic Jack

Side  IO
2 * USB 3.0 / 2 * USB 2.0 Ports
Power Adapter DC 5.5mm 19V~4.74A / 19V~9.74A (1x 90W/120W/150W Power adaptor outside )
Button

1 * Power switch button, 1 * Reset switch button

KB/MS 2.4G wireless keyboard and mouse set, or wired keyboard and mouse set (optional)
OS Windows 10
Dimensions
543mm (L)*321mm (H)*55.5mm (D)
